R65 (2472) | Electrical System
FUSE BOX/STOP LIGHT SWITCH
Diagram #61_0244 | 12 parts | 1 available in shop
100%
Parts List (12)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 61 13 1 244 038 | FUSE BOX (to 01/91) | 1 | |
| 2 | 61 13 8 760 138 | FUSE - 8A (to 01/91) | 1 | |
| 3 | 61 13 1 244 301 | HOLDER | 1 | |
| 4 | 07 11 9 932 033 | WAVE WASHER - B4 | 1 | |
| 5 | 07 11 9 907 946 | FILLISTER HEAD SELF-TAPPING SCREW - ST4,2X13 | 1 | |
| 6 | 07 12 9 952 119 | HOSE CLAMP - L42-48 | 1 | |
| 7 | 61 13 1 244 225 | COVER | 1 | |
| 8 | 61 13 1 243 678 | COVER | 1 | |
| 9 | 61 13 1 367 599 | CABLE TIE - L=200MM/B=3,6MM | 1 | |
| 9 | 61 13 1 377 134 | CABLE TIE - L=292MM/B=4,8MM | 1 | |
| 10 | 61 31 1 459 569 | SWITCH | 1 | |
| 12 | 07 11 9 921 607 | HEX NUT - M8X1 | 1 |
