K1100LT (89V2) | Vehicle Trim
PAINTED PARTS 697 FJORDGRAU
Diagram #51_0137 | 23 parts | 7 available in shop
100%
Parts List (23)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 46 63 2 324 298 | UPPER CASING OF ANTENNA - FJORDGRAY | 1 | |
| 2 | 46 63 2 309 265 | COVER - BLACK | 1 | |
| 3 | 46 63 2 324 303 | MIRROR LEFT - FJORDGRAY | 1 | |
| 3 | 46 63 2 324 304 | MIRROR RIGHT - FJORDGRAY | 1 | |
| 4 | 46 63 2 324 299 | RADIOTOR TRIM PANEL CENTER - FJORDGRAY | 1 | |
| 5 | 46 63 2 324 286 | TRIM PANEL LOWER RIGHT - FJORDGRAY | 1 | |
| 5 | 46 63 2 324 301 | TRIM PANEL LOWER LEFT - FJORDGRAY | 1 | |
| 6 | 46 61 2 324 291 | FRONT MUDGUARD - FJORDGRAY | 1 | |
| 7 | 46 61 2 324 292 | FRONT MUD GUARD, REAR - FJORDGRAY | 1 | |
| 8 | 16 11 2 323 364 | FUEL TANK - FJORDGRAY | 1 | |
| 9 | 46 63 2 324 293 | COVERING LEFT - FJORDGRAY | 1 | |
| 9 | 46 63 2 324 294 | COVERING RIGHT - FJORDGRAY | 1 | |
| 10 | 46 63 2 324 305 | TAIL PART UPPER - FJORDGRAY | 1 | |
| 11 | 46 54 2 324 283 | TOP CASE - FJORDGRAY | 1 | |
| 12 | 46 54 2 316 651 | COVER - FJORDGRAY | 1 | |
| 13 | 46 54 2 324 763 | INTEGRAL CASE LEFT - FJORDGRAY | 1 | |
| 13 | 46 54 2 324 764 | INTEGRAL CASE RIGHT - FJORDGRAY | 1 | |
| 14 | 46 54 2 324 287 | COVER LEFT - FJORDGRAY | 1 | |
| 14 | 46 54 2 324 288 | COVER RIGHT - FJORDGRAY | 1 | |
| 15 | 51 91 0 145 930 | BASE PAINT, TWO-COAT FJORDGRAY - 500ML 310 | 1 | |
| 15 | 51 91 0 302 097 | SET: TOUCH-UP STICK FJORDGRAY MET. - 2X12ML 310 | 1 | |
| 15 | 51 91 1 052 235 | SET: SPRAY-PAINT FJORDGRAY MET. - 2X150ML 310 | 1 | |
| 15 | 51 91 2 301 354 | RULING INK SILVER - 250ML 124 | 1 |
