F650 Funduro (E169) | Rear Axle & Suspension
MODIFICATION KIT F LOWER CHASSIS
Diagram #33_0680 | 11 parts
100%
Parts List (11)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33 53 2 319 149 | SET: MODIFICATION KIT F LOWER CHASSIS | - | |
| 2 | 33 53 2 316 761 | TENSION STRUT | - | |
| 3 | 33 53 2 345 443 | BUSH | - | |
| 4 | 33 53 2 316 762 | BASE | - | |
| 5 | 33 53 2 345 533 | SELF-LOCKING HEX NUT - M12 | - | |
| 6 | 07 11 9 900 531 | HEX NUT - M10-05-ZNS | - | |
07 12 9 904 002 | SELF-LOCKING HEX NUT - M8-8-ZNS3Alternative for position 6 | - | ||
07 12 9 964 672 | SELF-LOCKING HEX NUT - M10Alternative for position 6 | - | ||
| 7 | 71 60 2 317 459 | SIDE STAND - KURZ | - | |
| 8 | 71 60 2 317 230 | STICK-ON LABEL | - | |
| 9 | 71 60 2 317 458 | CENTER STAND - KURZ | - |
