F650GS 01-04 (R13) | Engine

PISTON WITH RINGS AND WRISTPIN

Diagram #11_2940 | 3 parts

100%
F650GS 01-04 (R13) PISTON WITH RINGS AND WRISTPIN exploded view parts diagram

Parts List (3)

#Part NumberDescriptionQty
1
11 25 7 652 879
PISTON - AB1
3
11 25 7 652 916
LOCK RING - 22MM1
4
11 25 7 652 980
REPAIR KIT PISTON1
