Parts List (9)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 31 42 7 105 801 | FORK LEG LEFT - BLACK | - | |
| 2 | 63 14 9 467 625 | REAR REFLECTOR YELLOW SIDE FRONT | - | |
| 4 | 46 63 9 908 452 | FILLISTER-HEAD SCREW - M8X30-8.8-MK | - | |
| - | 31 42 7 105 802 | FORK LEG RIGHT - BLACK | - | |
| - | 63 14 9 467 625 | REAR REFLECTOR YELLOW SIDE FRONT | - | |
| 4 | 46 63 9 908 452 | FILLISTER-HEAD SCREW - M8X30-8.8-MK | - | |
| - | 07 12 9 907 380 | ISA SCREW - M8X35-8.8-ZNNIV | - | |
| 4 | 63 14 9 467 625 | REAR REFLECTOR YELLOW SIDE FRONT | - | |
| 5 | 83 19 2 470 714 | TELESCOPIC FORK OIL TYPE 4 - 1000ML | - |
BMW numbers positions across the whole assembly group and lists only the parts supplied for this model, so the drawing can show numbers that do not appear in this list.
