R1250GS 21 (K50) | Vehicle Trim
PAINTED PARTS WND2 BLACK-STORM MET.
Diagram #51_Z431 | 8 parts | 1 available in shop
100%
Parts List (8)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 46 61 8 567 896 | FRONT WHEEL FENDER, UPPER - BLACK | 1 | |
| 1 | 51 14 9 457 797 | LOGOTYPE, FRONT-WHEEL COVER, LEFT - EDITION | 1 | |
| 1 | 51 14 9 457 798 | LOGOTYPE, FRONT-WHEEL COVER, RIGHT - EDITION | 1 | |
| 2 | 46 63 8 567 899 | TANK COVER, CENTER - BLACK | 1 | |
| 3 | 46 63 1 542 393 | TANK TRIM, LEFT - BLACKSTORM | 1 | |
| 1 | 51 14 9 457 799 | LOGOTYPE SIDE TRIM PANEL, LEFT - EDITION | 1 | |
| 3 | 46 63 1 542 394 | TANK TRIM, RIGHT - BLACKSTORM | 1 | |
| 1 | 51 14 9 457 800 | LOGOTYPE SIDE TRIM PANEL, RIGHT - EDITION | 1 |
