Parts List (37)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 11 14 8 405 478 | FRONT COVER MILLED - CLASSIC | 1 | |
| 1 | 11 14 8 405 515 | FRONT COVER MILLED - STORM | 1 | |
| 1 | 11 14 8 405 516 | FRONT COVER MILLED - HP | 1 | |
| 1 | 11 14 9 829 741 | CRANKCASE COVER FRONT MILLED - SHADOW | 1 | |
| 2 | 11 12 8 405 481 | CYLINDER HEAD COVER, MILLED, LEFT - CLASSIC | 1 | |
| 2 | 11 12 8 405 482 | CYLINDER HEAD COVER, MILLED, LEFT - CLASSIC | 1 | |
| 2 | 11 12 8 405 485 | CYLINDER HEAD COVER, MILLED, LEFT - STORM | 1 | |
| 2 | 11 12 8 405 486 | CYLINDER HEAD COVER, MILLED, LEFT - STORM | 1 | |
| 2 | 11 12 8 405 489 | CYLINDER HEAD COVER, MILLED, LEFT - HP/SHADOW | 1 | |
| 2 | 11 12 8 405 490 | CYLINDER HEAD COVER, MILLED, LEFT - HP/SHADOW | 1 | |
| 3 | 07 11 9 904 950 | O-RING - 27X3,2 | 1 | |
| 4 | 11 12 8 396 740 | OIL FILLER PLUG - CLASSIC | 1 | |
| 4 | 11 12 8 394 848 | OIL FILLER PLUG - STORM | 1 | |
| 4 | 11 12 8 405 514 | OIL FILLER PLUG - HP | 1 | |
| 4 | 11 12 9 829 725 | OIL FILLER PLUG - SHADOW | 1 | |
| 5 | 11 12 8 405 507 | COVERING LEFT - CLASS.STOR.SHA. | 1 | |
| 5 | 11 12 8 405 508 | COVERING RIGHT - CLASS.STOR.SHA. | 1 | |
| 6 | 11 12 8 405 503 | IGNITION COIL COVER, MILLED, LEFT - HP | 1 | |
| 6 | 11 12 8 405 504 | IGNITION COIL COVER, MILLED, RIGHT - HP | 1 | |
| 6 | 11 12 8 405 495 | IGNITION COIL COVER, MILLED, LEFT - CLASSIC | 1 | |
| 6 | 11 12 8 405 496 | IGNITION COIL COVER, MILLED, RIGHT - CLASSIC | 1 | |
| 6 | 11 12 9 829 735 | IGNITION COIL COVER, MILLED, LEFT - SHADOW | 1 | |
| 6 | 11 12 9 829 736 | IGNITION COIL COVER, MILLED, RIGHT - SHADOW | 1 | |
| 7 | 61 31 8 547 664 | BODY SCREW WITHOUT SHOULDER - M6X16 A2 MK | 1 | |
| 8 | 11 12 8 393 252 | RUBBER | 1 | |
| 9 | 11 12 8 393 277 | RUBBER ELEMENT | 1 | |
| 10 | 07 11 9 907 038 | DOWEL PIN - 5M6X10 | 1 | |
| 11 | 77 12 9 444 601 | ABRASIVE PAD, BLACK, LEFT | 1 | |
| 11 | 77 12 9 444 602 | ABRASIVE PAD, BLACK, RIGHT | 1 | |
| 11 | 11 12 8 405 494 | SLIDER PAD, RIGHT | 1 | |
| 11 | 11 12 9 829 849 | SLIDER PAD, LEFT - BLUE | 1 | |
| 11 | 11 12 9 829 850 | SLIDER PAD, RIGHT - BLUE | 1 | |
| 11 | 11 12 9 829 745 | SKID PAD YELLOW LEFT | 1 | |
| 11 | 11 12 9 829 746 | SKID PAD YELLOW RIGHT | 1 | |
| 12 | 07 12 9 907 402 | FILLISTER-HEAD SCREW - M6X20-8.8-ZNNIV | 1 | |
| 13 | 11 12 9 457 298 | BADGE | 1 | |
| 14 | 11 12 9 457 299 | BADGE | 1 |
