R1150GS ADV (R21A) | Steering
SINGLE PARTS, CLUTCH FITTING
Diagram #32_0953 | 19 parts | 6 available in shop
100%
Parts List (19)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 21 52 2 333 162 | LEVER, CHOKE CONTROL | 1 | |
| 2 | 32 72 2 333 048 | COUNTERSUNK HEAD SCREW - M4X20 4.8 | 1 | |
| 3 | 32 72 2 333 414 | COVER, LOWER HANDLEBAR FITTINGS | 1 | |
| 4 | 32 72 2 333 059 | COUNTERSUNK HEAD SCREW - M5X8 | 1 | |
| 5 | 32 72 7 669 512 | RUBBER BOOT | 1 | |
| 6 | 32 72 2 333 056 | COVER, GRIP UNIT, BLACK | 1 | |
| 6 | 71 60 7 655 488 | COVER, GRIP UNIT, CHROME | 1 | |
| 7 | 32 72 2 333 065 | COUNTERSUNK HEAD SCREW - M4X16 | 1 | |
| 8 | 32 72 2 333 061 | COUNTERSUNK HEAD SCREW - M6X25 8.8 | 1 | |
| 9 | 32 72 2 311 141 | 0.01 | 1 | |
| 10 | 32 72 7 665 445 | MAINTENANCE KIT, PISTON - D=13MM | 1 | |
| 11 | 32 72 2 333 062 | LOCK RING - D=16MM | 1 | |
| 12 | 32 72 2 333 063 | RUBBER BOOT | 1 | |
| 13 | 32 72 2 333 064 | GRUB SCREW | 1 | |
| 14 | 32 72 7 651 451 | BEARING SCREW, HAND LEVER | 1 | |
| 15 | 32 72 2 333 066 | FILLISTER-HEAD SCREW - M2X12 4.8 (to 09/07) | 1 | |
| 15 | 07 11 9 907 425 | COUNTERSUNK SCREW - M2X12-8.8-MK | 1 | |
| 16 | 61 31 2 305 735 | CLUTCH SWITCH | 1 | |
| 17 | 21 52 2 333 434 | COUNTERSUNK HEAD SCREW - M3X8 | 1 |
