R1100GS (259E) | Rear Axle & Suspension
REAR WHEEL SWINGING ARM
Diagram #33_0669 | 16 parts | 3 available in shop
100%
Parts List (16)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33 17 2 312 566 | REAR WHEEL SWINGING ARM | 1 | |
| 2 | 33 17 2 312 147 | RUBBER MOUNTING | 1 | |
| 3 | 33 17 2 311 528 | RUBBER BOOT | 1 | |
| 4 | 33 17 2 311 527 | SNAP RING | 1 | |
| 5 | 33 17 2 311 729 | TAPERED ROLLER BEARING - 17X40X13,25 | 1 | |
| 6 | 33 17 2 312 563 | PIVOT PIN, RIGHT | 1 | |
| 7 | 33 17 2 311 074 | PIVOT PIN, LEFT | 1 | |
| 8 | 33 17 2 312 217 | HEX NUT | 1 | |
| 9 | 33 17 2 310 890 | PIVOT PIN | 1 | |
| 1 | 33 17 2 331 095 | ADHESIVE LOCTITE 2701 - 10ML | 1 | |
| 10 | 33 17 1 452 504 | RUBBER BOOT | 1 | |
| 11 | 33 17 1 458 197 | TENSION STRAP - D=85MM | 1 | |
| 11 | 33 17 2 335 139 | CABLE TIE - L=450MM | 1 | |
| 12 | 33 17 2 335 120 | TENSION STRAP - D=132MM | 1 | |
| 13 | 46 63 1 235 660 | PLUG | 1 | |
| 14 | 33 17 2 331 095 | ADHESIVE LOCTITE 2701 - 10ML | 1 |
