R1100GS (259E) | Frame, Fairing, Cases
FAIRING SIDE SECTION
Diagram #46_0289 | 11 parts | 2 available in shop
100%
Parts List (11)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 16 11 2 313 603 | SUPPORT LEFT (to 09/95) | 1 | |
| 1 | 16 11 2 313 604 | SUPPORT RIGHT (to 09/95) | 1 | |
| 1 | 16 11 2 324 979 | SUPPORT LEFT - + 5 MM (to 09/95) | 1 | |
| 1 | 16 11 2 324 980 | SUPPORT RIGHT - + 5 MM (to 09/95) | 1 | |
| 1 | 46 63 2 324 873 | SUPPORT F LEFT SHEET-STEEL FUEL TANK (from 10/95) | 1 | |
| 1 | 46 63 2 324 874 | SUPPORT F RIGHT SHEET-STEEL FUEL TANK (from 10/95) | 1 | |
| 2 | 46 63 1 453 058 | EXPANDING NUT | 1 | |
| 3 | 07 11 9 900 474 | SHEET METAL SCREW - 3,5X13-Z2 | 1 | |
| 4 | 34 32 2 331 053 | EDGE PROTECTION - L=110MM | 1 | |
| 5 | 46 63 2 313 895 | LATERAL TRIM PANEL LEFT - SILVER | 1 | |
| 5 | 46 63 2 313 896 | LATERAL TRIM PANEL RIGHT - SILVER | 1 |
