Parts List (18)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 34 32 2 312 443 | BRAKE HOSE | - | |
| 2 | 34 32 1 242 205 | HOLLOW BOLT | - | |
| 3 | 07 11 9 963 072 | GASKET RING - A10X13,5-CU | - | |
| 4 | 34 32 1 455 018 | GROMMET, RIGHT | - | |
| 5 | 31 42 1 457 233 | HOSE CLAMP | - | |
| 6 | 34 32 1 237 259 | GROMMET | - | |
| 7 | 34 32 2 312 692 | BRAKE PIPE (to 05/92) | - | |
34 32 2 312 693 | BRAKE PIPE (from 05/92)Alternative for position 7 | - | ||
| 8 | 34 32 2 312 695 | LEFT RUBBER SOCKET | - | |
34 32 2 312 696 | GROMMET, RIGHTAlternative for position 8 | - | ||
| 9 | 34 32 2 310 917 | GROMMET | - | |
| 10 | 46 62 2 309 944 | PLUG | - | |
| 11 | 61 13 1 369 668 | CABLE HOLDER - D=16,7MM | - | |
| 12 | 34 32 1 236 462 | GROMMET | - | |
| 13 | 83 13 2 445 461 | BRAKE FLUID DOT4 LV, LOW VISCOSITY - 1L (to 01/96) | - | |
83105A87362 | BRAKE FLUID DOT4 LV, LOW VISCOSITY - 1LAlternative for position 13 | - | ||
83 13 2 467 961 | BRAKE FLUID DOT4 LV, LOW VISCOSITY - 250ML (to 01/96)Alternative for position 13 | - | ||
83105A87361 | BRAKE FLUID DOT4 LV, LOW VISCOSITY - 250MLAlternative for position 13 | - |
