Parts List (12)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 11 12 7 106 166 | ROCKER BOX COVER RIGHT | - | |
| 2 | 11 12 8 526 288 | OIL COVER LID | - | |
| - | 07 11 9 904 950 | O-RING - 27X3,2 | - | |
| 3 | 07 11 9 904 950 | O-RING - 27X3,2 | - | |
| 4 | 11 12 7 108 464 | IGNITION COIL COVER, RIGHT | - | |
| 5 | 11 12 7 106 165 | ROCKER BOX COVER LEFT | - | |
| 6 | 11 12 7 108 463 | IGNITION COIL COVER, LEFT | - | |
| 7 | 46 63 8 534 943 | BODY SCREW WITHOUT SHOULDER - M5X14 MK | - | |
| 8 | 11 12 7 698 958 | SCREW WITH BUSH | - | |
| 9 | 11 12 7 710 489 | TWIST PROTECTION, LEFT | - | |
11 12 7 710 490 | TWIST PROTECTION, RIGHTAlternative for position 9 | - | ||
| 10 | 11 12 1 024 824 | SET: SEAL SET FOR CYLINDER HEAD COVER | - |
