Parts List (13)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 46 63 7 656 007 | COVERING FUEL TANK | - | |
46 63 7 652 684 | COVERING FUEL TANKAlternative for position 1 | - | ||
46 63 7 673 206 | COVERING FUEL TANKAlternative for position 1 | - | ||
46 63 7 673 204 | COVERING FUEL TANK - YELLOW 2Alternative for position 1 | - | ||
46 63 7 652 592 | COVERING FUEL TANKAlternative for position 1 | - | ||
46 63 7 652 593 | COVERING FUEL TANKAlternative for position 1 | - | ||
46 63 7 652 591 | COVERING FUEL TANK - RED 2Alternative for position 1 | - | ||
46 63 7 652 576 | COVERING FUEL TANK - REDAlternative for position 1 | - | ||
46 63 7 673 205 | COVERING FUEL TANKAlternative for position 1 | - | ||
| 2 | 06 32 7 651 212 | BINDING HEAD SCREW - M5X16-A2-80 (to 12/99) | - | |
06 32 7 657 949 | FILLISTER HEAD SCREW - M5X16-A2-80-MKAlternative for position 2 | - | ||
| 3 | 46 63 7 651 465 | PLUG-IN NUT - M5 | - | |
| 4 | 46 63 7 651 263 | GASKET | - |
