R65 (2472) | Rear Axle & Suspension
REAR WHEEL SWINGING ARM
Diagram #33_0642 | 10 parts | 2 available in shop
100%
Parts List (10)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33 17 1 452 094 | REAR WHEEL SWINGING ARM | 1 | |
| 2 | 33 17 1 241 546 | TAPERED ROLLER BEARING - 40X17X17 | 1 | |
| 3 | 33 17 1 236 955 | PIVOT PIN - L=42,5MM | 1 | |
| 4 | 33 53 3 054 174 | HEX NUT | 1 | |
| 5 | 33 17 1 230 296 | 0.01 | 1 | |
| 6 | 33 17 1 237 789 | 0.01 | 1 | |
| 6 | 33 17 1 237 7891 | CAD PLATED NUT | 1 | |
| 7 | 33 17 1 230 304 | RUBBER COVER | 1 | |
| 7 | 3318304 | BOOT | 1 | |
| 8 | 33 17 1 458 346 | TENSION STRAP - D=83MM | 1 |
