R1200GS 05-07 (K25) | Brakes
FRONT BRAKE RIVET PACKAGE
Diagram #34_1813 | 29 parts | 10 available in shop
100%
Parts List (29)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 34 11 7 713 158 | BRAKE ROTOR, OFFSET, FRONT - D=305-4,5MM | 1 | |
| 2 | 34 52 8 549 506 | SENSOR RING (from 08/06) | 1 | |
| 2 | 34 52 7 667 325 | SENSOR RING, FRONT, INTEGRAL ABS (to 08/06) | 1 | |
| 3 | 34 11 7 713 039 | OVAL HEAD SCREW - M8X20MK | 1 | |
| 3 | 36 31 7 709 543 | OVAL HEAD SCREW - M8X25-10.9 ZNS3 | 1 | |
| 4 | 34 11 7 684 959 | BRAKE CALIPER EVO WITHOUT PAD, LEFT - D=32/36MM | 1 | |
| 4 | 34 11 7 684 960 | BRAKE CALIPER EVO WITHOUT PAD, RIGHT - D=32/36MM | 1 | |
| 5 | 34 11 8 520 872 | VENT SCREW | 1 | |
| 6 | 34 21 1 236 794 | DUST CAP | 1 | |
| 7 | 34 11 7 713 338 | ISA SCREW - M8X32-10.9 ZNS3 | 1 | |
| 8 | 34 11 2 338 257 | SET: REPAIR BRAKE CALIPER - D=32/36MM | 1 | |
| 9 | 34 11 7 660 850 | SET: MOUNTING PARTS SET | 1 | |
| 10 | 34 11 7 671 780 | SET: OF BRAKE PADS, SINTERED METAL - BREMBO | 1 | |
| 2 | 34 11 7 660 850 | SET: MOUNTING PARTS SET | 1 | |
| 10 | 34 11 8 534 183 | SET: SET OF BRAKE PADS, SINTERED METAL | 1 | |
| 10 | 83 12 2 296 187 | Brake Pad Paste - 5 ml | 1 | |
| 2 | 34 11 7 660 850 | SET: MOUNTING PARTS SET | 1 | |
| 11 | 34 52 7 677 824 | WHEELSPEED SENSOR (08/06 to 08/22) | 1 | |
| 11 | 34 52 1 690 046 | WHEEL SPEED SENSOR (from 08/06) | 1 | |
| 11 | 34 51 7 666 436 | WHEELSPEED SENSOR (to 08/06) | 1 | |
| 12 | 36 31 7 678 083 | OVAL HEAD SCREW - M5X10-10.9 ZNS3 | 1 | |
| 13 | 34 51 7 706 354 | SPACER RING (to 08/06) | 1 | |
| 14 | 34 52 7 712 490 | CABLE CLAMP | 1 | |
| 15 | 34 51 7 695 906 | CABLE HOLDER (to 08/06) | 1 | |
| 16 | 07 11 9 900 439 | SELF TAPPING SCREW - CM4X10 (to 08/06) | 1 | |
| 17 | 07 14 7 566 122 | FIXING CLAMP - A=4,0 - 4,5MM | 1 | |
| 18 | 34 52 7 664 098 | CABLE CLAMP - D=6/4,5MM | 1 | |
| 19 | 83 19 2 158 852 | BRAKE PAD PASTE - 100G | 1 | |
| 20 | 61 13 1 367 599 | CABLE TIE - L=200MM/B=3,6MM | 1 |
