R100GS (47E1) | Frame, Fairing, Cases
CASE HOLDER F LOW EXHAUST SYSTEM
Diagram #46_0343 | 21 parts | 2 available in shop
100%
Parts List (21)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 46 54 2 316 550 | SET: LEFT CASE HOLDER SET - CHROME | 1 | |
| 1 | 46 54 2 316 551 | SET: LEFT CASE HOLDER SET - BLACK | 1 | |
| 2 | 46 54 2 316 359 | LEFT CASE HOLDER - BLACK | 1 | |
| 2 | 46 54 2 316 361 | LEFT CASE HOLDER - CHROME | 1 | |
| 3 | 07 12 9 901 130 | ISA SCREW - M6X20-8.8-ZNNIV | 1 | |
| 3 | 23 11 2 322 407.1 | M6X20 ALLEN BOLT STAINLESS | 1 | |
| 4 | 07 11 9 904 202 | WASHER - A6,4-ZNNIV SI | 1 | |
| 5 | 07 12 9 922 705 | SELF-LOCKING HEX NUT - M6-10 ZN (to 02/96) | 1 | |
| 5 | 07 14 7 575 163 | SELF-LOCKING HEX NUT - M6 ZNNIV SI | 1 | |
| 5 | 07 14 7 575 163 | SELF-LOCKING HEX NUT | 1 | |
| 6 | 46 54 2 316 362 | CASE ROD - BLACK | 1 | |
| 7 | 72 60 2 315 672 | CLAMP - BLACK | 1 | |
| 7 | 72 60 2 315 674 | CLAMP - POLIERT | 1 | |
| 8 | 07 11 9 919 801 | FILLISTER-HEAD SCREW - M6X16 | 1 | |
| 9 | 07 11 9 932 073 | SPRING WASHER BLACK - B6-ZN | 1 | |
| 9 | 07 11 9 932 099 | WAVE WASHER - B6 6,4X12 | 1 | |
| 9 | 07 11 9 932 0701 | SS 6MM WASHER | 1 | |
| 9 | 07 11 9 932 073 | BLACK SPRING WASHER | 1 | |
| 9 | 07 11 9 936 439 | WASHER - 5.3-140 HV-ZNS | 1 | |
| 9 | 07 11 9 904 496 | WAVE WASHER - B6-ZNS3 | 1 | |
| 10 | 62 21 1 459 439 | SEALING STRIP - 60X15X4 | 1 |
