K1100LT (89V2) | Frame, Fairing, Cases
RETROFIT KIT, LUGGAGE COMPARTMENT NET
Diagram #46_0313 | 14 parts | 2 available in shop
100%
Parts List (14)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 46 54 2 315 904 | SET: COMFORT SET, TOP CASE - TOP CASE 35 L | 1 | |
| 2 | 11 14 1 338 429 | WASHER-GASKET | 1 | |
| 3 | 46 63 2 300 370 | CAP NUT - M6 | 1 | |
| 4 | 46 54 2 316 323 | LUGGAGE NET | 1 | |
| 5 | 18 22 1 464 332 | FILLISTER HEAD SCREW | 1 | |
| 6 | 46 63 2 316 418 | WASHER - 6,4 SW | 1 | |
| 7 | 07 11 9 932 073 | SPRING WASHER BLACK - B6-ZN | 1 | |
| 8 | 46 54 2 316 325 | MIRROR | 1 | |
| 9 | 46 54 2 316 324 | COVER | 1 | |
| 10 | 63 31 1 376 046 | INTERIOR LIGHT | 1 | |
| 11 | 63 31 1 374 798 | BULB - 5W | 1 | |
| 12 | 46 63 2 309 201 | SHEET METAL SCREW - ST 4,2X19 | 1 | |
| 12 | 46 63 2 309 201 | SHEET METAL SCREW | 1 | |
| 13 | 46 63 1 235 759 | GROMMET | 1 |
