Parts List (23)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 63 17 1 244 342 | SIGNALLING LIGHT,BLUE - ULO | 1 | |
| 1 | 63 17 1 244 343 | SIGNALLING LIGHT,RED - ULO | 1 | |
| 2 | 63 17 1 244 345 | LENS BLUE - ULO | 1 | |
| 2 | 63 17 1 244 346 | LENS RED - ULO | 1 | |
| 3 | 63 17 1 244 348 | BULB SOCKET - ULO | 1 | |
| 4 | 63 17 1 244 349 | PROTECTION CAP - ULO | 1 | |
| 5 | 07 11 9 978 055 | BULB - 12V 35W | 1 | |
| 6 | 63 17 1 244 351 | BOW - ULO | 1 | |
| 7 | 61 31 1 353 795 | RUBBER WASHER | 1 | |
| 8 | 61 13 1 244 360 | GROMMET | 1 | |
| 9 | 07 11 9 901 766 | WASHER - A13/HV-ZNS (to 12/96) | 1 | |
| 9 | 07 11 9 904 119 | WASHER - 12-300 HV-ZNS3 | 1 | |
| 10 | 46 63 2 300 372 | BUSH | 1 | |
| 11 | 46 63 2 300 375 | GROMMET | 1 | |
| 12 | 46 63 2 300 113 | BRACKET LEFT | 1 | |
| 12 | 46 63 2 300 114 | BRACKET RIGHT | 1 | |
| 13 | 46 63 2 300 135 | CLAMP | 1 | |
| 14 | 07 11 9 931 044 | WASHER - 6,4 (to 03/90) | 1 | |
| 15 | 07 12 9 905 536 | ISA SCREW - M6X16-8.8-ZNNIV | 1 | |
| 16 | 07 12 9 922 705 | SELF-LOCKING HEX NUT - M6-10 ZN (to 03/90) | 1 | |
| 15 | 07 11 9 901 438.1 | M6X16 SS ALLEN BOLT | 1 | |
| 16 | 07 14 7 575 163 | SELF-LOCKING HEX NUT - M6 ZNNIV SI | 1 | |
| 16 | 07 14 7 575 163 | SELF-LOCKING HEX NUT | 1 |
