K100 (K589) | Exhaust System
SET, MOUNTING PARTS, EXHAUST SYSTEM
Diagram #18_0289 | 19 parts | 3 available in shop
100%
Parts List (19)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 18 12 1 340 921 | SET: SET OF PARTS F CATALYST AND EXHAUST (from 09/85) | 1 | |
| 1 | 46 71 2 316 572 | SET: MODIFICATION KIT F SAFETY BAR, CATALYST - CHROME (from 09/85) | 1 | |
| 1 | 46 63 2 316 477 | SET: MOUNTING PARTS SET F ENGINE SPOILER,CAT. (from 09/85) | 1 | |
| 1 | 18 12 1 464 529 | MUFFLER, CATALYTIC CONVERTER (from 09/85) | 1 | |
| 2 | 16 11 2 309 404 | INTERMEDIATE PLATE - KAT (from 09/85) | 1 | |
| 3 | 07 11 9 918 519 | SELF TAPPING SCREW - M4X8 (from 09/85) | 1 | |
| 4 | 51 14 2 121 497 | LABEL "UNLEADED FUEL" (from 09/85) | 1 | |
| 5 | 23 31 1 464 225 | SHIFT LEVER (from 09/85) | 1 | |
| 6 | 23 31 1 451 767 | BUSHING (from 09/85) | 1 | |
| 7 | 18 21 1 461 922 | GROMMET (from 09/85) | 1 | |
| 8 | 18 21 1 464 152 | SUPPORT (from 09/85) | 1 | |
| 9 | 18 12 1 464 754 | ABSORBER (from 09/85) | 1 | |
| 10 | 18 21 1 464 095 | NUT - M8 (from 09/85) | 1 | |
| 11 | 18 21 1 464 213 | INSULATING WASHER (from 09/85) | 1 | |
| 12 | 07 11 9 901 107 | FILLISTER-HEAD SCREW - M10X60-8.8 (from 09/85) | 1 | |
| 13 | 18 12 1 464 528 | BUSH (from 09/85) | 1 | |
| 14 | 18 21 1 461 923 | WASHER (from 09/85) | 1 | |
| 15 | 07 11 9 907 088 | HEX NUT - M10 (from 09/85) | 1 | |
| 16 | 07 11 9 905 230 | SPLIT PIN - 2X16 (from 09/85) | 1 |
