Parts List (9)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 51 47 7 655 605 | ALUMINUM CRASH BAR | - | |
| 2 | 46 63 1 451 277 | RUBBER GROMMET | - | |
| 3 | 46 63 1 451 278 | INSERT | - | |
| 4 | 46 63 1 451 275 | BUSH - 25X6.4X10-ZNS3 | - | |
| 5 | 77 41 7 723 472 | SET: INSTALLATION KIT, ALUMINUM CRASH BAR | - | |
| 6 | 07 12 9 903 807 | ISA SCREW - M6X25-8.8-ZNS3 | - | |
| 7 | 07 14 9 151 606 | WASHER - 6,4-25-1,5MM | - | |
| 8 | 51 12 7 070 202 | C-CLIP NUT - M6-ZNS3 | - | |
| 9 | 77 01 7 723 478 | INST. INSTR., UNDERRIDE PROTECTION | - |
