F800GS 08 (K72) | Steering
SINGLE PARTS, PARKING BRAKE FITTING
Diagram #32_1787 | 26 parts | 2 available in shop
100%
Parts List (26)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 32 72 7 691 942 | HANDBRAKE LEVER | 1 | |
| 2 | 32 72 7 673 990 | SLEEVE | 1 | |
| 3 | 32 72 7 673 989 | COUNTERSUNK HEAD SCREW - M5X30 | 1 | |
| 4 | 07 11 9 905 729 | HEX NUT - M5-8-ZNNIV SI | 1 | |
| 5 | 32 72 7 728 847 | SET: EXPANSION TANK, SMOKED GLASS | 1 | |
| 6 | 32 72 7 723 459 | SET: SET OF CAPS, FLUID RESERVOIR, BRAKES | 1 | |
| 7 | 32 72 7 673 999 | RUBBER BOOT | 1 | |
| 8 | 32 72 7 704 761 | HOSE | 1 | |
| 9 | 32 72 7 702 049 | HOSE CLAMP | 1 | |
| 10 | 32 72 8 523 904 | SET: CONNECTOR | 1 | |
| 11 | 32 72 7 675 117 | O-RING | 1 | |
| 12 | 32 72 7 673 919 | DUST PROTECTION COLLAR | 1 | |
| 13 | 32 72 7 673 917 | CLAMP WITH MIRROR MOUNT - M5 | 1 | |
| 13 | 32 72 7 723 084 | PIPE CLAMP RIGHT | 1 | |
| 14 | 32 72 7 705 874 | ISA SCREW - M5X35 A4-70 | 1 | |
| 15 | 61 31 7 671 111 | MICROSWITCH | 1 | |
| 1 | 32 72 7 673 996 | GRUB SCREW - M4X8 | 1 | |
| 1 | 32 72 7 675 747 | THRUST ADAPTER | 1 | |
| 16 | 32 72 7 675 747 | THRUST ADAPTER | 1 | |
| 17 | 32 72 7 673 996 | GRUB SCREW - M4X8 | 1 | |
| 18 | 32 72 7 719 817 | BRACKET EXPANSION TANK | 1 | |
| 1 | 62 21 7 670 749 | RUBBER GROMMET - 8X18X12MM | 1 | |
| 19 | 62 21 7 670 749 | RUBBER GROMMET - 8X18X12MM | 1 | |
| 20 | 07 12 9 904 491 | ISA SCREW - M5X10 | 1 | |
| 21 | 32 72 7 723 093 | BRACKET | 1 | |
| 22 | 07 12 9 904 849 | ISA SCREW - M5X12-8.8-ZNNIV | 1 |
