Parts List (12)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 11 24 8 537 752 | CONNECTING ROD WITH BUSHING (to 03/09) | 1 | |
| 2 | 11 25 7 722 754 | GUDGEON PIN - D18X11X50 (to 03/09) | 1 | |
| 1 | 11 24 8 537 752 | CONNECTING ROD WITH BUSHING (from 03/09) | 1 | |
| – | 11 25 7 722 754 | GUDGEON PIN - D18X11X50 (from 03/09) | 1 | |
| 2 | 11 24 7 688 359 | CONNECTING ROD BOLT - M9X1X49 | 1 | |
| 3 | 11 24 7 690 500 | CONNECTING ROD BEARING - 45X48X15 | 1 | |
| 4 | 11 27 7 702 426 | BALANCE ROD WITH ROCKER | 1 | |
| 5 | 11 27 7 688 360 | CONNECTING ROD BOLT - M12X1,25X54 | 1 | |
| 6 | 11 27 7 690 501 | BEARING SHELL | 1 | |
| 7 | 11 41 2 343 108 | ROLL PIN - 4X29,8 | 1 | |
| 8 | 11 27 7 722 182 | BOLT | 1 | |
| 9 | 11 27 2 343 243 | WOODRUFF KEY - 4X5 | 1 |
