F650ST (E169) | Steering

HANDBRAKE LEVER

Name: Dapper Motor
Address: Haarlem, Noord-Holland, NL
Telephone: +31232077747
Price range: €€€

Diagram #32_0798 | 16 parts

100%

Parts List (16)

#	Part Number	Description	Qty
1	32 72 2 345 320	HANDBRAKE LEVER - D=13MM	-
2	32 72 2 345 424	HANDBRAKE LEVER	-
3	32 72 2 345 423	COVER	-
4	32 72 2 345 427	CLAMPING	-
5	32 72 2 345 430	SCREW	-
6	32 72 2 345 425	COVER	-
7	32 72 2 345 428	SCREW	-
8	32 72 2 345 429	SCREW - 4X12	-
9	32 72 2 345 466	THRUST ADAPTER	-
10	61 31 2 346 504	FRONT STOP LIGHT SWITCH	-
11	61 31 2 345 554	FILLISTER-HEAD SCREW - M2X12	-
12	61 31 2 345 555	HEX NUT, FLAT - M2	-
13	32 72 2 345 301	STOP DISK	-
14	32 72 2 345 299	HANDLE TUBE	-
15	32 72 2 345 300	HANDLE RIGHT	-
16	32 72 2 345 565	INSPECTION GLASS	-
