F650ST (E169) | Pedals
BRAKE PEDAL
Diagram #35_0177 | 8 parts
100%
Parts List (8)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 35 21 2 345 682 | BRAKE PEDAL | - | |
| 2 | 07 12 9 905 113 | ISA SCREW WITH WASHER - M8X80 | - | |
| 3 | 27 72 2 345 480 | O-RING - D=13,95X2,62 | - | |
| 4 | 35 21 2 345 309 | SPRING | - | |
| 5 | 35 21 2 345 453 | BALL JOINT - M6 | - | |
| 6 | 35 21 2 345 310 | 0.02 | - | |
| 7 | 07 11 9 905 543 | HEX NUT - M6-8-ZNNIV SI | - | |
| 8 | 63 14 2 346 469 | HEX NUT - M6 | - |
