F650ST (E169) | Exhaust System
EXHAUST SYSTEM PARTS WITH MOUNTS
Diagram #18_0287 | 21 parts
100%
Parts List (21)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 18 12 2 345 147 | MUFFLER, CATALYTIC CONVERTER - 80 DB | - | |
| 2 | 18 11 2 345 180 | EXHAUST PIPE, RIGHT - SLS | - | |
| 3 | 18 11 2 345 035 | EXHAUST PIPE LEFT | - | |
| 4 | 18 11 2 345 040 | CLAMP | - | |
| 5 | 18 11 2 345 038 | GASKET | - | |
| 6 | 18 11 2 345 041 | CLAMP | - | |
| 7 | 18 11 2 345 037 | GASKET | - | |
| 8 | 18 11 2 345 039 | GASKET | - | |
| 9 | 18 21 2 345 045 | FLANGE | - | |
| 10 | 18 11 2 345 086 | HEX NUT - M8 | - | |
| 11 | 18 12 2 345 042 | COVER | - | |
| 12 | 18 12 2 345 043 | COVER | - | |
| 13 | 18 11 2 345 072 | INSULATING WASHER | - | |
| 14 | 07 11 9 932 0701 | SS 6MM WASHER | - | |
07 11 9 932 073 | SPRING WASHER BLACK - B6-ZN (to 08/90)Alternative for position 14 | - | ||
07 11 9 932 073 | BLACK SPRING WASHERAlternative for position 14 | - | ||
07 11 9 904 446 | WASHER - 5-200 HV-ZNNIVAlternative for position 14 | - | ||
| 15 | 18 11 2 345 087 | FLANGE SCREW - M6X16 | - | |
| 16 | 18 11 2 345 088 | HEX BOLT - M8X16 | - | |
| 17 | 07 14 9 180 923 | WASHER - 8,4X18X2MM | - | |
| 18 | 46 63 7 650 963 | BUMP STOP | - |
