Parts List (10)
| # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 71 21 7 655 253 | LABEL "ORIGINAL BMW TEILE" | - | |
| 3 | 71 21 1 341 178 | LABEL "UNLEADED FUEL" | - | |
| 4 | 71 21 7 652 617 | LABEL "NOISE INSTRUCTION" - USA (to 05/01) | - | |
71 21 7 666 798 | LABEL "NOISE INSTRUCTION" - USA (05/01 to 12/01)Alternative for position 4 | - | ||
71 21 7 672 769 | LABEL "NOISE INSTRUCTION" - USA (from 12/01)Alternative for position 4 | - | ||
| 6 | 71 21 7 652 616 | LABEL "EXHAUST EMISSION" - USA (to 05/01) | - | |
71 21 7 666 793 | LABEL "EXHAUST EMISSION" - USA (05/01 to 12/01)Alternative for position 6 | - | ||
71 21 7 672 768 | LABEL "EXHAUST EMISSION" - USA (from 12/01)Alternative for position 6 | - | ||
| 7 | 71 21 7 657 923 | ABS LABEL | - | |
| 12 | 71 21 7 655 256 | LABEL "TIRE WARRANTY" | - |
BMW numbers positions across the whole assembly group and lists only the parts supplied for this model, so the drawing can show numbers that do not appear in this list.
