F650GS 01-04 (R13) | Electrical System

FUSES

Diagram #61_5768 | 4 parts

100%
F650GS 01-04 (R13) FUSES exploded view parts diagram

Parts List (4)

#Part NumberDescriptionQty
3
61 13 1 372 524
FUSE BROWN - 7,5A1
3
61 13 1 372 526
FUSE BLUE - 15A1
3
61 13 1 372 527
FUSE MAXI, YELLOW - 20A1
8
61 13 7 668 722
GRIPPER CLIP FOR MINIATURE FUSES1
